Details
Utilizing a hum/single/hum (five-coil) pickup layout and unique electronics configuration, the Modern Eagle V gives players a vast array of tones in one guitar. The 5-way blade switch selects the pickups in intuitive groupings: treble, treble and middle, middle, middle and bass, and bass. There is a single volume and a push/pull tone control that activates both humbuckers when engaged; this allows players to access all three pickups simultaneously. Finally, the dual EQ mini-toggle switches act as tuned high-pass filters when engaged (in the up position), removing shelved low-end and allowing the high frequencies through for more clarity and musical highs.
Body Construction: Solidbody
Top Wood: Maple
Back Wood: Mahogany
Top Carve: Violin
Number of Frets: 22
Scale Length: 25"
Neck Wood: Mahogany
Neck Construction: One-Piece
Truss Rod: PRS Double-Acting
Neck Shape: Pattern
Neck Width at the Nut: 1 11/16"
Fretboard Wood: Rosewood
Fretboard Radius: 10"
Fretboard Inlay: Birds
Headstock Logo: Signature, Inlaid
Neck/Body Assembly Type: Set
Finish Type: High-Gloss Nitro
Bridge: PRS Patented Tremolo, Gen III
Tuners: PRS Phase III Locking Tuners with Wing Buttons
Nut: Bone
Truss Rod Cover: "Modern Eagle V"
Treble Pickup: TCI
Middle Pickup: NS-01
Bass Pickup: TCI
Controls: Volume, Push/Pull Tone, 5-Way Blade, Two Mini-Toggle Coil-Tap Switches
Case: Hardshell Case - Reviews
-
